Automatic Carpet Fabric Cutting Machine

TIMING automatic carpet fabric cutting machines are designed for precise single-layer cutting of carpet fabrics using computer-controlled systems. They can accurately cut thick carpet materials into various shapes, sizes, and custom patterns with high consistency.

Equipped with industrial cutting blades, these machines handle dense fibers efficiently and may include functions such as automatic blade sharpening, pattern digitization, and conveyor-assisted material handling for smoother workflow.

By replacing manual cutting, the system significantly improves production efficiency, reduces labor costs, and increases output speed. At the same time, optimized nesting and cutting paths help minimize material waste, allowing manufacturers to lower production costs and improve overall profitability.



What is the cutting speed range of the TIMING machine?

The machine is built with a full closed-loop servo system and TIMING motion control technology.

Speed range: 0–60 m/min, continuously adjustable

One-touch switching between high-speed and precision modes

High-speed mode for denim, woven fabrics, bulk orders

Low-speed mode for stretch, lightweight and coated fabrics

It supports on-the-fly cutting, meaning feeding and cutting run at the same time without stopping the workflow.

What cutting accuracy can be expected?

With intelligent knife control and real-time compensation:

Standard tolerance: ≤ ±0.5 mm

Stable accuracy across single and multi-layer cutting

High consistency between layers in stack cutting

The vertical down-cut structure keeps edges straight, avoids slanted cuts, and eliminates fiber pulling or burrs.

What is the maximum cutting thickness?

Depending on configuration and compression system:

Standard compressed cutting thickness: 30–90 mm

Vacuum stacking capacity: up to 75 mm

Thin fabrics: up to 100 layers

Medium-heavy fabrics: 10–40 layers

What is the machine lifespan?

Machine lifespan: over 10 years

Core components: 80,000–120,000 working hours

Designed for continuous industrial production

*Versatility

*High Speed

*High Accuracy

*Ease to use and easy in maintenance

*Low cost

*Space-saving

Work Width	1600/1800/2000mm
Normal Working Length	Standard 2500mm
Customized Length Range	800mm ~5000mm
Customized Width Range	800mm ~2600mm
Cutting Speed	0mm/s ~ 1500mm/s
Tool Configuration	Tungsten steel straight knife , round knife , and other tools like V notch, I notch etc optional
Drive Motor	Servo Motor
Vibration Cutter	Vibration speed 16000/Min RPM 80W motor
Material Fixed Method	Vacuum absorb
Data format	DXF, PLT, HPGL
Air pressure, Flow	0.55MPa 100L/min
Vacuum Pump Power	7.5KW/9KW
Working Voltage/ Frequency	AC220V ± 22V,50Hz ± 1Hz
Vacuum Pump Working Voltage/ Frequency	AC380V ± 38V,50Hz ± 1Hz
Work Environment	Temperature 0°~ 40° Humidity 20% ~ 80%

How much floor space is required?

The system is modular.

Working width: 170 / 200 / 220 cm

Extendable cutting table

Suitable for both small workshops and large factories

What are the power and air requirements?

Power supply: 220V / 380V / optional 110V

Air pressure (optional modules): 0.4–0.6 MPa

Stable operation under global industrial grids

What safety systems are included?

The machine is equipped with multiple protection layers:

Infrared emergency stop detection

Dual physical emergency stop buttons

Overload protection

Anti-collision system

Automatic fault shutdown
